Original DSE2548 Genuine LED Output Expansion Module DSE 2548 Diesel Generator Set Controller

Original DSE2548 Genuine LED Output Expansion Module DSE 2548 Diesel Generator Set Controller

$350.00 USD
$0.00 USD $350.00 USD
ลดราคา ขายหมดแล้ว
ค่าจัดส่งที่คำนวณในขั้นตอนการชำระเงิน
DSE2548 Genuine LED Output Expansion Module Diesel Generator Set Controller DSE 2548


DSE2548

DSENet® LED Output (8) Expansion Module

The DSE2548 is an output expansion module that can display a maximum of eight individual LED indications. Each indication is user configurable via the host module.

Up to 10 DSE2548 modules can be linked together to provide up to 80 additional LED outputs.

OVERALL SIZE
180 mm x 116 mm x 43 mm (7.1” x 4.6” x 1.7”)
PANEL CUTOUT SIZE
154 mm x 98 mm (6.0” x 3.9”)
MAXIMUM PANEL THICKNESS
8.0mm (0.3”)
WEIGHT
0.36kg
PRODUCT VARIANTS
2548-01 - 2548 Output Expansion Module


SPECIFICATION
DC SUPPLY
CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous

CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking.

MAXIMUM OPERATING CURRENT
112 mA at 12 V, 53 mA at 24 V
MAXIMUM STANDBY CURRENT
74 mA at 12 V, 35 mA at 24 V

DIMENSIONS
OVERALL
180 mm x 116 mm x 42.7 mm
7.07” x 4.57” x 1.68”
PANEL CUT-OUT
154 mm x 98 mm
6.06” x 3.86”
MAXIMUM PANEL THICKNESS
8 mm
0.3

Key Features
  • Panel mount.
  • Vertical design.
  • In-built alarm.
  • Alarm mute button.
  • Power on/link lost LED.
  • Connect maximum of 10 x DSE2548’s to a single host controller.
  • Max of 80 configurable LED’s.
