DSE2133
DSENet® RTD/Thermocouple Input (8) Expansion Module
The DSE2133 is an RTD/thermocouple input expansion module providing 8 additional inputs to the control module. Up to 4 DSE2133 modules can be linked together to provide up to 32 additional inputs.
Designed to give greater input flexibility for meeting complex industry generator control specifications.
Inputs can be configured as RTD or thermocouple and are controlled from within the host control module.
OVERALL SIZE
165 mm x 76 mm x 49 mm (6.5” x 3.0” x 1.9”)
WEIGHT
0.22kg
PRODUCT VARIANTS
2133-01 - 2133 RTD/Thermocouple Input Expansion Module
SPECIFICATION
8V to 35V continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs will not be maintained during cranking.
MAXIMUM OPERATING CURRENT: 56 mA at 12 V, 20 mA at 24 V
INPUT: 8 inputs configurable as RTD/Thermocouple
DIMENSIONS
OVERALL
165 mm x 76 mm x 49 mm
6.5” x 3” x 1.9”
STORAGE TEMPERATURE RANGE
-40 oC to +85 oC
KEY FEATURES
• Power on/Link lost LED
• 4 modules can be connected to 1 host controller at a time
• 8 inputs configurable for J-type/K-type thermocouple, PT 100, 3 wire RTD sensors
• Works up to 1.2 km (0.75 miles) from the host module
• Terminal strip connection for quick and easy set-up
