Original Deep Sea DSEL401 MKII Lighting Tower Control Module Generator Intelligent Controller
Original Deep Sea DSEL401 MKII Lighting Tower Control Module Generator Intelligent Controller
ราคาปกติ
$600.00 USD
ราคาปกติ
$0.00 USD
ราคาโปรโมชัน
$600.00 USD
ราคาต่อหน่วย
/
ต่อ
ค่าจัดส่งที่คำนวณในขั้นตอนการชำระเงิน
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
Deep Sea DSEL401 MKII Lighting Tower Control Module Original Generator Intelligent Controller DSEL401MKII
DSEL401 MKII
Intelligent Lighting Tower Control Module
The DSEL401 MKII is an intelligent control module designed specifically for mobile lighting tower applications. The control module provides class leading flexible features that are fully configurable to suit multiple complex lighting sequences.
OVERALL SIZE：140 mm x 113 mm x 43 mm (5.5” x 4.4” x 1.7”)
PANEL CUTOUT SIZE：118 mm x 92 mm (4.6” x 3.6”)
MAXIMUM PANEL THICKNESS：8.0mm (0.3”)
PRODUCT VARIANTS：L401-01 - L401 MKII Intelligent Lighting Tower Control Module (Rtc)
WEIGHT：0.28kg
PACKAGE: Carton Packageing
WARRANY：12 Months Factory Warranty
· DC SUPPLY
CONTINUOUS VOLTAGE RATING
8 V to 35 V Continuous
· CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking.
· MAXIMUM OPERATING CURRENT：85 mA at 12 V, 96 mA at 24 V
· MAXIMUM STANDBY CURRENT：51 mA at 12 V, 47 mA at 24 V
· MAXIMUM SLEEP CURRENT：35 mA at 12 V, 32 mA at 24 V
· MAXIMUM DEEP SLEEP CURRENT：<10 uA at 12 V, <10 uA at 24 V
· OUTPUTS
OUTPUT A (FUEL): 10 A short term, 5 A continuous, at supply voltage
OUTPUT B (START): 10 A short term, 5 A continuous, at supply voltage
AUXILIARY OUTPUTS C to J: 2 A DC at supply voltage
· GENERATOR
VOLTAGE RANGE: 15 V to 415 V AC (Ph to N)
26 V to 719 V AC (Ph to Ph)
FREQUENCY RANGE: 3.5 Hz to 75 Hz
· DIMENSIONS
OVERALL
140 mm x 113 mm x 43 mm
5.5’’ x 4.4” x 1.7”
PANEL CUT-OUT
118 mm x 92 mm
4.6’’ x 3.6”
· STORAGE TEMPERATURE RANGE
-40 °C to +85 °C
-40 °F to +185 °F
· OPERATING TEMPERATURE RANGE
NON HEATED DISPLAY VARIANT
-30 °C to +70 °C
-22 °F to +158 °F
HEATED DISPLAY VARIANT
-40 °C to +70 °C
-40 °F to +158 °F
