Original Genuine UK DeepSea DSE2157 DSENet Relay Expansion Module 8 Configurable Volt-Free Relays 4NO+4CO LED

Original DSE2157 Extended Relay Output Expansion Module UK Deep Sea

DSE2157

DSENet® Output (8) Expansion Module

Overview

The DSE2157 Output Expansion Module has been developed for use with a wide range of DSE products. The DSE2157 extends the host modules output capabilities for increased application flexibility. This is achieved by providing an additional 4 normally open volt-free contacts and 4 changeover volt-free contacts.

For enhanced communication with the host module, the DSE2157 features a DSENet® port for connection to a wide range of DSE products. A red status LED is provided to easily identify when the DSE2157 is connected to a power source and communicating with the host controller.

OVERALL SIZE
165 mm x 76 mm x 49 mm (6.5” x 3.0” x 1.9”)
WEIGHT
0.28kg
PRODUCT VARIANTS
2157-01 - 2157 Output Expansion Module

Key Features
• 4 Normally Open Volt-Free Contacts
• 4 Changeover Volt-Free Contacts
• Status LED to Indicate Power On and Link Lost
• DSENet® Communication
