Original DSE3110 replace DSE402 MKII for low specs ATS Controller Panel Genset Spare Parts Control Module Unit
DSE3110
Manual & Auto Start Control Module
The DSE3110 is an outstanding compact control module that provides a comprehensive range of features for single-set applications. The controller can be used in manual or auto start mode.
Specification
Model: DSE3110
Brand: Deep Sea Electronics (DSE)
Condition: Genuine Original
Function: Manual & Auto Start Controller for single genset
Display: Back-lit icon LCD, LED alarm indicator
Digital Inputs: 6 Nos
Digital Outputs: 4 Nos
Power Supply: 8V ~ 35V DC continuous
Frequency Range: 3.5Hz ~75Hz
Sensing Options: Magnetic Pick-up(MPU) / CANbus engine version
Programming: Front panel or DSE Configuration Suite PC software
Panel Front Rating: IP65
Application: Single diesel/gas generator set, engine-only control, standby power system
Warranty: 12 months genuine factory warranty
OVERALL SIZE
98 mm x 79 mm x 40 mm (3.9” x 3.1” x 1.6”)
PANEL CUTOUT SIZE
80 mm x 68 mm (3.1 " x 2.7") MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
WEIGHT
0.16kg
PRODUCT VARIANTS
3110-01 - Manual & Auto Start Control Module (Mpu)
