Original DATAKOM DKG105 AMF Generator Controller Digital LED Display Mains Failure Auto Start Stop Control Module

Product Specifications

• Model: Genuine DATAKOM DKG105 AMF Generator Controller
• Power Supply: DC 9~33V Wide Voltage (12V/24V Universal)
• Display: 3-Digit Red LED Multi-Parameter Cyclic Display
• Core Functions: Mains Failure Auto Start/Stop, ATS Load Transfer, Multi-Fault Protection, Hour Recording, Digital Parameter Setting
• I/O Rated Current: Each Relay Channel Max 10A
• Mounting: Standard 72×72mm Embedded Panel Installation
• Operating Temperature: -20℃ ~ +70℃
• Net Weight: 0.2KG
• Package: Carton Packaging
• Warranty: 12 Months Factory Warranty
•

Wide Application Range

1. 5-150kVA single standby diesel/gas generator ATS automatic control cabinet
2. Residential, fire emergency, shopping mall small key load backup power system
3. Telecom base station, remote unattended off-grid agricultural irrigation power station
4. Construction site temporary mobile generator, rental genset automation retrofitting
5. Small marine auxiliary generator, water pump unit automatic control upgrade

Key Product Features

1. Standard 72×72mm Universal Panel Size, Plug-In Quick Replacement
   Industry general square mounting dimension, pluggable green terminal block, no complicated wiring modification, can directly replace old DKG series, HGM series, DSE compact controllers, greatly shortening on-site maintenance downtime
