Original ComAp IL‑NT S‑USB Plug‑In USB Service Communication Module For InteliLite NT InteliCompact NT

Original ComAp IL‑NT S‑USB Service Communication Module

IL-NT S-USB

Order code: IL-NT-S-USB

Specification

• Product: Original ComAp IL‑NT S‑USB Service Communication Module
• Part Number: IL‑NT‑S‑USB
• Brand: Original ComAp
• Type: Plug‑in / easily removable USB service card
• Slot: IL‑NT controller COMMUNICATION MODULE port
• Port: USB slave (USB Type‑B), internally connected to controller COM1
• Driver: FTDI USB‑serial virtual COM port (VCP) on Windows
• Connection: Shielded USB A–B cable, max length 5 m (recommended 1.8 m ComAp USB‑link cable)
• Supported Software: ComAp InteliConfig (config, monitoring, firmware, history)
• Protocols: ComAp service protocol, Modbus over USB
• Compatible Controllers: InteliLite NT, InteliCompact NT, InteliDrive Lite (and variants / "clones" under the IL‑NT platform)
• Use Case: Field commissioning, warranty service, bench programming, retrofit debugging, factory‑line testing
• Condition: 100% Original ComAp brand new
• Dimension: 5.5*6.5*1cm
• Net Weight: 0.03kg
• Warranty: 12months genuine factory warranty

The IL NT S-USB offers

• Easily removable plug-in communication module for InteliLite NT, InteliCompact NT, InteliDrive Lite and InteliPro controllers and other controller variants from these families
• Connecting the controller to ComAp’s software tool LiteEdit
